QP-HE10 High Voltage Protection Power Supply for static eliminator

Short Description:

Output Voltage: 4.6/5.6/7KV (Optional)

Min Order Quantity:1 Piece/Pieces

Supply Ability:1000 Piece/Pieces per Month



Payment Terms:L/C,D/A,D/P,T/T

package:wooden case/ carton

Product Detail

Product Tags

QP-HE10 High Voltage Protection Power Supply Is A Highly Efficient, Safe, And Intelligent Product Developed And Designed By Qipu. It Has Detection, Protection, And Indication Functions For Short Circuit, Ignition, Undervoltage, Overload, And Overvoltage Faults. It Can Detect The Operating Status Of The Product In Real Time, Quickly Cut Off The Output In Case Of Abnormalities, And Protect The Safety Of The Product And Operators In Real Time. The Working Status Is Displayed Through The Display Interface; The High-voltage Plug Adopts A Brand New Design Without External Grounding Wire,Avoiding The Danger Caused By Poor Contact And Disconnection Of The Grounding Wire; An External Port Is Also Provided,Which Can Output Working Status Signals.
Output Voltage 4.6/5.6/7KV (Optional)
Low Operating Cost (28W Power)
The New High-voltage Connection Line Integrates A Grounding Wire,
Which Is More Convenient And Safer Than The Old Split Connection
The Indicator Light Displays The Working Status
Work Status Can Be Outputted
Real Time Protection For Short Circuits, Ignition, And Safer Use
Can Supply Power To 2 Electrostatic Eliminators

performance parameter

Model QP-HE10
Input Voltage 220V/50Hz Maximum Load 12m(4.6/5.6KV) 4.5m(7KV)
Power 28W External Dimensions L * W * H 192*180*105.5mm
Output Voltage 4.6/5.6/7KV (Optional) Weight 3.2Kg
Output Current MAX 5mA Working Temperature 0~50℃
Number Of Connected Loads 2 Working Humidity 0~70%RH(No Freezing, No Condensation)

Size Parameter
